              High Quality Automatic Blow Molding Machine
              • High Quality Automatic Blow Molding MachineHigh Quality Automatic Blow Molding Machine

              High Quality Automatic Blow Molding Machine

              ERUSUN-SA series blow moulding machine is the latest high output semi-automatic PET blow moulding machine. Comparing to the traditional machine design, thanks to new concept of automatic bottle discharging unit, the patented heating system and the preforms automatic lo......

              Send Inquiry

              Product Description

              ERUSUN-SA series blow moulding machine is the latest high output semi-automatic PET blow moulding machine. Comparing to the traditional machine design, thanks to new concept of automatic bottle discharging unit, the patented heating system and the preforms automatic loading design, The SA series blow molding machine requires less manpower and reducing the work intension for the operator. New SA series blow moulding machine holds the cavity of the blowing mold up to 6 cavities, the output reaches 1800BPH for 500ml water bottles. Compared to the output of normal manual blow moulding machine, this is an outstanding improvement in the PET Bottle blow molding industry.
              M odelSA 4SA6
              Number of Cavities4Cavity6Cavity
              MaterialPET/PC/PP/PEPET/PC/PP/PE
              Clamping Force180KN300KN
              Max Clamping Stroke350mm250mm
              Bottom Moving Stroke60mm60mm
              Max. Stretching Stroke380mm380mm
              Theoretical Output2000BPH2800BPH
              Max. area of mould base620*420mm750*420mm
              Max. Mould Thickness190mm190mm
              Space Between Tie Bars550*340mm670*340mm
              Electrical system
              Voltage Standard380v/3PH/50Hz or special order
              Total power(Full Loaded)15KW18KW
              Container
              Max l ength of preform180mm180mm
              Diameter of preform15mm-40mm15mm-40mm
              Container Volume0.1-2.5L0.1-1.0L
              Diameter of neck finish15mm-45mm15mm-30mm
              Container Diameter110mm70mm
              Max. Height of container370mm250mm
              Air system
              High pressure Air compressor>1.2m /3.0MPax23 (0.5L)
              Dimension & Weight
              Blow molding machine1.9*0.88*1.8M
              Oven1.9*0.66*1.6M
              Net Weight1.3T
