Full-Automatic Foam EVA Shoe Injection Moulding Machine (3 stations)
Technical DescriptionMould Closing SystemWork Stations 3Clamping Force (kg) 150000Mould-Opening Stroke (mm) 350Standard Thickness of Mould (mm) 100-210Mould Plate Size (mm) 2(290*550)Height of Injection Nozzle (mm) 60 Method of Heating electricHeating Power (kw) 8.04Injection SystemI......
Send Inquiry
Product Description
Technical Description
1.Low operation height,Operation height in accord with human engineering
2.Extra height opening stroke
Act by fixed opening stroke: 350mm, which is not affected by any mould thickness changes and
3.available for 2plates mould,Mould thickness adjusting mechanism
Mould adjusting scope: 100-200MM
4.Rapid mould opening ,Act by toggle mechanism which opens the mould rapidly
5.Speedy injector movement
Driven by linear-track, allowing speedy moving and precise positioning,Energy saving design
6.No need water circulation for mould station
7.Space saving design,Put oil tank together with injection base, which makes the structure compact and saves more space.
FAQ:
1. What is your terms of delivery?
We accept EXW, FOB, CFR, CIF, etc. You can choose the one which is the most convenient
2.What type of your product?
We are one of the most professional and biggest manufacture of shoe machine equipment.
3.What machines you have in your factory?
EVA injection molding machine, PVC single/double color air - blowing machine, sport shoes knot injection molding machine, upper molding machine, rain boot molding machine.
| Mould Closing System | ||
| Work Stations | 3 | |
| Clamping Force (kg) | 150000 | |
| Mould-Opening Stroke (mm) | 350 | |
| Standard Thickness of Mould (mm) | 100-210 | |
| Mould Plate Size (mm) | 2(290*550) | |
| Height of Injection Nozzle (mm) | 60 | |
| Method of Heating | electric | |
| Heating Power (kw) | 8.04 | |
| Injection System | ||
| Injectors (set) | 2 | |
| Diameter of Screw (mm) | 60 | |
| Max Injection Capacity (cc) | 860 | |
| Injection Pressure | 1100 | |
| Injection Speed (cm/sec) | 10 | |
| Rotating Speed of Screw (r.p.m) | 0-190 | |
| Temperature Control (section) | 4 | |
| Electricity Consumption | ||
| Heater Barrel (kw) | 6.05 | |
| Motor for Injector Moving (kw) | 1.5 | |
| Heating Board of Mould (kw) | 25.6 | |
| Hydraulic System (kw)(50hz) | 22 | |
| Vacuum Pump (kw) | 2.2 | |
| Cooling Fan of Barrel (HP) | 1 | |
| Total Electricity (kw) | 75 | |
| Oil Tank Size (L) | 1000 | |
| Machine Weight (kg) | 12000 | |
2.Extra height opening stroke
Act by fixed opening stroke: 350mm, which is not affected by any mould thickness changes and
3.available for 2plates mould,Mould thickness adjusting mechanism
Mould adjusting scope: 100-200MM
4.Rapid mould opening ,Act by toggle mechanism which opens the mould rapidly
5.Speedy injector movement
Driven by linear-track, allowing speedy moving and precise positioning,Energy saving design
6.No need water circulation for mould station
7.Space saving design,Put oil tank together with injection base, which makes the structure compact and saves more space.
FAQ:1. What is your terms of delivery?
We accept EXW, FOB, CFR, CIF, etc. You can choose the one which is the most convenient
2.What type of your product?
We are one of the most professional and biggest manufacture of shoe machine equipment.
3.What machines you have in your factory?
EVA injection molding machine, PVC single/double color air - blowing machine, sport shoes knot injection molding machine, upper molding machine, rain boot molding machine.
